All Electric Injection Molding Machine

Performance characteristic:

High rigid toggle  structure with 5 pins and self-lock, fast response speed, lead to smooth mold open/close, structure self-lock after high-pressure clamping, lengthen the service life of clamping ball screw and mold.

Professional controller for all electric injection molding machine has friendship human-computer interface,  rapid and accuracy  process control, easy operate, powerful function

All kind of curves display and inspection,modern production management and technology control

Compact and robust machine bed is high precision and minimum wear and tear on the mold. Safety relay of mold matains the stablility and security of motion

High efficiency lubrication system, use the graphite alloy steel sleeve (copper sleeve), reduce oil usage and make machine more clean and durable

Zero-resistance clamping injection guider structure, heavy loaded guider device supported by linear track, better wear resistance, lower friction and more smooth operation. Optimize mold structure, tie bar no touch with moving platen, no lubrication. The system has high rigidity and strength, guarantee the accuracy of platen parallel excellently.

T-slot & screw fixation platen embedded mold locating ring design, high-standard clampling system reduces mold loss and makes more easy mold installation.

Fast and smooth mold movement, high torque, less resistance. Clamping servo motorcon- nects ball screw, flexible operation and simply maintenance. High- quailty belt, warranty 10 years; superior rotating wheel, low inertia.

Top  responsibility servo  motor and  high torque  ball screw  is  key element, origin Japan technology to keep advantage leading in the word, precise for mold movement.

Parameters

Overall dimensions:

Platen dimensions:
