SPDC Series
MFGSP
8418699090
CHINA
Brand new with guarantee
Immediate
Depending on specification
Size: | |
---|---|
Availability: | |
Product Description
As the clean cooling water is available, it's widely used in the industries with high demands of the cooling water quality, such as the electronic, food, chermical, casting, air conditioner and refrigeration industries. It's able to be applied for mould cooling to reduce the product's molding cycle, which also can be used for equipment cooling to ensure that the equipment is maintained at normal temperature, or other working areas which need cooling.
Features
● Modular design and easy capacity expansion help to reduce the
impact of failure maintenance;
● Easy installation: small modular volume, convenient transportation,
which only needs to connect the power supply and water pipe to put into operation.
● Economic energy saving: take ambient air as the cooling medium
without the compressor to save the cost, and the whole water loop
adopts hermetic circulation with little water consumption that greatly saves the resource.
● Aluminum air filter that is easy to clean.
● Evaporative wet curtain: In the summer, it can directly spray the
running water to improve the heat exchange efficiency and maintain constant water temperature in the process. The spraying time is unlimited, high efficient and maintenance-free.
● Super wide heat exchanger
● Equipped with temperature control meter for temperature display at
any moment;
Wide type heat exchanger
● Equipped with anti-freezing measures and the ambient temperature
is lower than 5℃, which can drain water automatically.
Machine Model | SPDC-45WS | SPDC-90WS | Grouping | Model | Type | ||
Refrigeration capacity | kW | 45 | 90 | ||||
Blower | n | 1 | 2 | ||||
Blower power | kW | 2.2 | 4.4 | Module combination | SPDC-180WS | 2×90WS | |
Air quantity | m³/h | 24000 | 48000 | ||||
Max.current | A | 5 | 10 | ||||
Rated water flow rate | m³/h | 10 | 20 | SPDC-270WS | 3×90WS | ||
L | mm | 1774.5 | 2974.5 | ||||
W | mm | 1804 | |||||
H | mm | 1962 | SPDC-360WS | 4×90WS | |||
Water pipe connection mode | Flange or clamp | ||||||
Pipe dimension | DN | 40 | 100 |
※We reserve the right to change specifications without prior notice.
