The device is applicable to centralized pulverizing of all kinds of plastics,including the waste of injection moulding,blow molding and extrusion forming.The structure of Crusher is compact for convenient operation,easy cleaning and maintenance which enhances the working efficiency.Low noise to make the working environment better.
Specifications:
Model
Chamber Calibre (mm)
Crush Capacity (kg/H)
Rotating Blade (Pcs)
Fixed Blade (Pcs)
Motor (Kw)
External Dimension LxWxH (mm)
Weight (kg)
SG-400JV
235x400
100-250
3x2
2x1
7.5
1250x850x1450
950
SG-500JV
290x500
150-300
3x2
2x2
11
1460x970x1660
1300
SG-600JV
320x600
200-350
3x2
2x2
15
1650x1580x1820
1800
SG-800JV
540x810
300-400
3x2
2x2
22
1930x1890x2300
2500
Note:The crushing capacity depends on the diameter of screen mesh.
※We reserve the right to change specifications without prior notice.
