Product Description
We employs segmented screws with a selfwiping profile to provide poptimum feeding properties for a wide range of raw materials such as fillers,fiberglass, talcum powder,calcium carbonate and carbonate and most inorganic materials.
Side feeders are used for the following reasons:
1·Reduction of wear costs in the melting section of the main screw and barrels
2·More gentle processing of fillers
3·Increase in throughput
4·Increase in quality through the enough fixing
5·Lower the cost
Our side feeders advantages:
1. Independently develop and produce gearboxes.
1) All gearboxes are machined by gear grinding,the accuracy is up to six grades, and carburizing and hardening the tooth surface, thus ensuring that the noise of gearboxes is very low.
2) gear casting is made of resin sand and machining center to ensure high precision.
3) the gearbox's bearing is imported from Germany.
4) the gearbox has unique design, long life and low noise.
5) the gearbox and screw element are connected by spline sleeve, which is very convenient to disassemble.
2. barrel is made of wear resistant alloy steel and cooled by water channel.
3. screw adopts modular screw, and the screw assembly can be adjusted according to different feeding materials to meet different feeding requirements
Specification:
Side feeder parameters | MFG25 | MFG35 | MFG45 | MFG58 | MFG63 | MFG70 | MFG95 | |
Barrel diameter(mm) | Φ25.5 | Φ35.6 | Φ45.5 | Φ58.5 | Φ63.5 | Φ71 | Φ96 | |
Screw(mm) | Φ25 | Φ35. 1 | Φ45 | Φ57.8 | Φ62.8 | Φ69 | Φ95 | |
Grove depth (mm) | 6 | 7.7 | 10.2 | 11.8 | 15 | 17.5 | 25.5 | |
Screw length (mm) | 248 | 360 | 444 | 495 | 495 | 426 | 960 | |
L/D | 9. 75:1 | 10:1 | 9. 75:1 | 8.5:1 | 8:1 | 6:1 | 10:1 | |
Motor power | 1. 5kw | 2 .2KW | 3KW | 4-5. 5KW | 5.5KW | 7. 5KW | 7. 5KW | |
Reducer Radio | 10:1 | 10:1 | 10:1 | 10:1 | 10:1 | 2.5:1 | 10:1 | |
Screw speed (rpm) | 245 | 300 | 300 | 307 | 307 | 600 | 245 | |
center to center distance A(m) | 19.5 | 28 | 35.8 | 48 | 48 | 53.5 | 72 | |
Size of cylinder feeding mouth (nm) | 44X120 | 85X40 | 120X75 | 80X140 | 80X140 | 110X180 | 215X150 | |
Feeding Capacity (kg/h) | GF (3-6mm〉 | -30 | -70 | -100 | -300 | -350 | -420 | -600 |
1250 talc powder 0. 4-0. 45kg/L | ~30 | ~70 | -100 | 〜300 | ~360 | ~440 | -600 | |
3000 talc powder 0.3-0.35kg/L | -030 | -30 | -50 | -150 | -200 | -270 | -300 |
Flange Joint size(mm) ![]() | X=73 | 80 | 113 | 125 | 125 | 144 | 198 | |
Y=60 | 70 | 78 | 106 | 106 | 90 | 133 | ||
C=64 | 70 | 75 | 98 | 98 | 76 | 122 | ||
ΦM=9 | 11 (M10) | 13.5 (M12) | 13.5 (M12) | 13.5 (M12) | 13.5 (M12) | 13.5 (M12) | ||
ΦD=Φ8H7 | Φ10H7 | Φ8H7 | Φ12H7 | Φ10H7 | Φ12H7 | Φ16H7 |
※We reserve the right to change specifications without prior notice.
