Applications
· Printing Machines
· Burning Machines
· Plastic Extruders, Laminating, Film Making Machines
· Uniform Temperature Equipment
· Household Machines
· Dust Collectors
· Textile Machines
· Pollution Machines
· Hot Air Blowers
· Dryers Machines
· Incinerators
· Machinery for the Food and Beverage Industries
· Machinery for Cooling
· Woodworking Machines
· Grain Elevators
· High pressure. Larger flow. Light weight.
· Aluminum alloy material was Widespread be use, offer light products.
· I.E.C. Designed motor(1HP UP), Squirrel Cage Induction Motors& specially designated shaft can satisfy long-time-continue operation.
· Professional impeller designed, high pressure, larger flow, Low noise, and long life.
· Special air-flow-adjust designs offer stable flows and easily control.
IE3Automatic motor Stator Winding / Wedge Inserter / Coil Forming Machinery
Manufacturing Rage:2.2kW~19kW
| Type | Phase | Frequency(Hz) | Power(KW) | Voltage(V) | Current(A) | Pressure (max)kPa | Air Flow m³/min(max) | Outler | Noise Level(dB) | Weight(Kgs) |
| CX-65 | 1φ
3φ | 50/60 | 0.19 | 220
220/380 | 1.5
1.1/0.9 | 0.7/1.1 | 4.5/5.3 | 65mm | 65/70 | 7 |
| CX-75SA | 1φ
3φ | 50/60 | 0.37 | 220
220/380 | 2.5
1.9/1.2 | 1.1/1.6 | 7/8 | 75mm | 70/75 | 10 |
| CX-75A | 1φ
3φ | 50/60 | 0.74 | 220
220/380 | 5
3/1.9 | 1.7/2.4 | 13/15 | 100mm | 75/80 | 16 |
| CX-100A | 3φ | 50/60 | 1.5 | 220/380 | 5.5/3.5 | 2/3 | 20/23 | 100mm | 82/90 | 26 |
| CX-125A | 3φ | 50/60 | 2.2 | 220/380 | 8/5 | 2.4/3.5 | 32/35 | 125mm | 87/95 | 37 |
| CX-150A | 3φ | 50/60 | 3.7 | 220/380 | 13/7.5 | 3.2/5.3 | 48/56 | 150mm | 92/100 | 52 |
| CX-150A-X(For 60Hz) | 3φ | 60 | 3.7 | 220/380 | 13/7.5 | 3.4 | 54 | 150mm | 100 | 51 |
※We reserve the right to change specifications without prior notice.
