Strong power copper-core motor is adopted, with fast speed and high energy conversion efficiency
Features
·High-quality ;lifelong maintenance ·High output ≥ 500KG/H ·The product is evenly granulated without dust ·Low noise ≤ 50DB ·The intelligent PLC control system makes the reverse direction when the material is jammed ·Long life ≥ 10 years
Parameter:
Model
SPD-400
SPD-600
SPD-800
SPD-1000
SPD-1200
SPD-1500
Chamber Calibre(mm)
405x500
605x500
805x950
1010x950
1210x950
1500x1000
Motor power(kw)
18.5
22
37
55
90
110
Cylinder stroke(mm)
450
550
1000
1000
1000
1000
Rotary cutter shaft diameter(mm)
230
230
320
320
350
380
Size of rotating blade(mm)
40x40
40x40
40x40
50x50
50x50
50x50
Rotating blade(Pcs)
21
30
56
56
68
84
Fixed blade(Pcs)
1
1
2
2
2
2
Hydraulic motor power
1.5
2.2
3
3
4
5.5
Hole size of mesh(mm)
30-80
30-80
30-80
30-80
30-80
30-80
Weight
1280
2100
3000
3500
3900
5800
Product quality advantage:
1 Rotating Blade Shaft The blade material is DC53, and the four corners can be replaced
2 Electric Box Sie mens programming control system is adopted to realize automatic control, with start, stop, reverse and overload automatic reverse control functions
3 Push box Through hydraulic control, the push box repeatedly pushes the material to the knife roll, significantly improving the output and even granulation of the product
4 Screen The size of the screen aperture determines the particle size of the product. Customers can choose the appropriate screen size and shape according to their needs
Effect display:
※We reserve the right to change specifications without prior notice.
