Rotary vibrating screen use upright motor as the source of vibration,equipped eccentricity hammer on the both sides of motor, change rotary motion to level, upright and incline movement, then pass these three movement to the surface of the screen. Adjust the phase angle on the both sides of the top and bottom to change the movement orbits of the surface screen.
Advantage:
● Any particle, powder and mucus can be screened within a certain range.
●Sifting to 1000 mesh or 0.002mm, and filtering to 2 microns.
●Grading screening, it can screen one to five layers of screen mesh, and can carry out two to six grades of sorting or filtering at the same time.
●High efficiency, compact and durable design, easy to change the screen, easy to operate and easy to clean.
● The rotary vibrating screen automatically discharges impurities and coarse materials, and can operate continuously.
●The mesh frame design, the screen mesh can be used for a long time, and the mesh is changed quickly, only 3-5 minutes.
●Small size, save space, easy to move.
Parameters
Model
A
B
C
D
E
F
H
I
I deck height ( mm)
2 deck height ( mm)
3 deck height ( mm)
Vibarion motor
( kw)
Common motor
( kw)
S49- 600
530
430
246
600
100
70
391
415
785
910
1040
0.25
0.75
S49- 800
680
580
246
800
125
80
514
430
855
1005
1155
0.55
1.1
S49- 1000
800
700
246
1000
150
95
615
430
865
1015
1065
1.1
1.5
S49- 1200
975
855
400
1200
180
100
717
550
1020
1170
1320
1.1
1.5
S49- 1500
1190
1050
400
1500
180
116
866
545
1090
1270
1440
1.5
2.2
S49- 1800
1580
1440
400
1800
200
150
1070
675
1230
1400
1570
3
3
S49- 2000
1800
1640
400
2000
200
190
1210
685
1280
1445
1615
3
3
※We reserve the right to change specifications without prior notice.
