    Helical Bevel Gearbox

    • SP Series

    • MFGSP

    • CHINA

    • Brand new with guarantee

    • Immediate

    • Depending on specification

    Availability:
    Inquire Add to Basket

    Product Description


    Helical Gearbox Key Features


    ● 26 model sizes for more unit selection and optimized applications

    ● Modular design with flange axis to accommodate horizontal, vertical and upright

    installations,which also enables gearbox to be installed in a narrow space.

    ● Non-contact concept and labyrinth seal for internal structure.

    ● New fan and diverse fan cover design increases thermal discharge capacity,cooler

    operation and greater efficiency.

    ● Optimized gear tooth profile for gearing accuracy,low wear, quiet and efficient

    operation.


    Helical Gearbox Specs


    Torque       2.58 to 551.6 KnM

    Ratios       6.3:1 to 450:1 standard ratios

    Housing    Cast Iron (standard), Ductile & Fabricated Steel (optional)

    Universal Housing     Horizontal, Vertical and Upright Mounting

    Low Speed Shaft      Solid, Hollow Bore with Shrink Disc or Keyed

    Auxiliary Cooling      Fan, Cooling Coil, Cooling Systems or forced oil cooling sysytem
