●Redesigned teeth reduce noise and provide smoother operation
●Overload capacity up to 500%
●Cycloidal tooth profile provides a high contact ratio to withstand overload shocks
●Compact size:single ratio available from6:1 to 119:1,double stage up to 7569:1& triple stage up to almost 1000000:1
●Ideal for dynamic applications: frequent start-stop-reversing duties suits for cyclo speed reducer since inertia is low
● Reduced TCO:high reliability,long life,minimal maintenance compared to conventional gearboxes
●Internal parts replaceable with other brands to ensure 24-7running
● Grease Lubricated & Oil Lubricated Models Available
● Output Shaft Rotation Direction: Single Reduction: Clockwise Rotation;Double Reduction→ Counter Clockwise Rotation
● Ambient Conditions: Indoor Installation:10-40 Celsius,Max85% Humidity, Under 1000m Altitude, Well Ventilated Environment, Free of corrosive,explosive gases, vapors and dust
● Slow Speed Shaft Direction: Horizontal, Vertical Up& Down, Universal Direction
● Mounting Style: Foot Mount,Flange Mount &VerticalF-flange Mount,
● Input Connection: Cyclo Integral Motor,Hollow Input Shaft Adapter,C-face Adapter,Top Mount, Shovel Bases
● Frame Size:607-627
●Ratio:6~658503
● Coupling Method With Driven Machine: Coupling, Gears,Chain Sprocket Or Belt
● Teco Cyclo Motor Capacity Range:0.2kW X4p～75kWX4p;15kWX6p~132kWX6p
