•Stable and smooth action,wear resistant and durable.
•The vertical axis adopted servo moter with accuracy to 0.1mm,high speed,heavyload,to increase production efficiency.Handheld control system adopts conversational operation which can be selected multiple languages view powerful function,and supports many groups of extension input/output to improve the automatic manufacture.
•Self-diagnostic system continually monitors input/output status and stores recent error message records.
•It can inspect the air presure automatically,it will alarm when its not safe.
•The robot has the CE standard complying with EUROMAP or SPI rules and the standard interface forming by the connection between EUROMAP12 or EUROPAP67 and molding machine.
Specifications:
Model
Robot Type
L.M.M. Rgnge (ton)
Vertical Stroke(mm)
Crosswise Stroke(mm)
Traverse Stroke(mm)
Gripper Angle
Max Load (includes gripper) (kg)
Minimum take out time (sec)
Cycle time (sec)
Drive System
Working Air Pressure (kgf/cm2)
Air Consumption(NL)
Power Consumption (KVA)
Power Supply
Weight (kg)
SHC-900W(D)
Telescopic type
250-320
W:900 D:900
W:300 D:150
1460
90
5
2.5
8
Z-Servo X、Y pneumatic
5-7
25
1.5
AC220V± 10%(50/60HZ)
400
SHC-1000W(D)
320-380
W:1000 D:1000
W:400 D:200
1950
10
3.5
10
28
1.5
430
SHC-1100W(D)
380-470
W:1100 D:1100
W:400 D:200
1950
10
3.5
10
28
1.5
440
SHC-1200W(D)
480-530
W:1200 D:1200
W:400 D:200
2190
10
3.5
10
30
1.5
450
SHC-1300W(D)
550-600
W:1300 D:1300
W:400 D:200
2190
10
3.5
10
32
1.5
460
SHC-1500W(D)
700-800
W:1500 D:1500
W:400 D:200
2300
15
5.0
15
40
2.0
600
Air Consumption for adsorption system 60NL/min
※We reserve the right to change specifications without prior notice.
