SP-2000-B Type two-step semi-automatic blowing machine blowing expertise within the 2-liter mineral water,beverages,oil, cosmetics,pesticides,civil bottles(PET、PP、PMMA、PC、PS、as raw materials)and other plastic containers,with a small size, consumption Electric province,operation and maintenance easy and so on.
SP-3P-A-type two-step semi-automatic computer-controlledinfrared oven heating professional blowing machine blowing volume of large diameter 28-120mm within 5L(PET,PP, ABS PMMA,PC,PS,as the raw material)plastic containers with high pressure,clamping force,small size,low power consumption operation and convenient maintenance.
Specification:
Type
Item
Unit
SP-2000
SP-2000-B
SP-2P-A
SP-3P-A
SP-4P-A
SP-5P
SP-2000-PP
Max. volume of product
l
2cavityx2L
2cavityx2L
2cavityx2L 1cavityx3L
2cavityx2L 1cavityx5L
2cavityx5L 1cavityx10L
5-20
2cavityx1.5L
Production capacity
Pcs/h
800-1100
1500-2000
450-950
450-900
300-400
120-200
500-800
Neck size of produce
mm
＜75
＜75
＜75
＜120
＜120
＜200
＜70
Clamping unit
Template effective area
mm
340x350
340x350
350x400
390x400
500x460
420x640
340x350
Max. mould thickness
mm
200
200
200
280
300
400
200
Min. mould thickness
mm
120
120
120
170
200
350
120
Mould stroke
mm
140
140
160
210
260
330
140
Clamping force
kn
80
80
100
100
100
100
80
Stretching stroke
mm
360
380
380
380
450
530
380
Air system
Working pressure
Mpa
≤1.0
≤1.0
≤1.0
≤1.0
≤1.0
0.8-1.0
≤1.0
Blowing air pressure
Mpa
SP-2000≤3.0
SP-2000-B≤3.0
SP-2P-A≤3.0
SP-3P-A≤3.0
SP-4P≤3.0
SP-5P≤3.0
SP-2000-PP≤3.0
Electric system
Power of machine
kw
0.1
0.1
0.1
0.1
0.1
0.1
0.1
Installed Power of heater
kw
9
11
16
16
38
38
40
Machine size
Weight of machine
kgs
485
485
670
800
1100
2000
570
Weight of heater
kgs
200
200
200
200
260
350
600
Machine size
m
1.45x0.59x1.65
1.45x0.59x1.65
1.64x0.6x1.65
1.8x0.63x1.75
2.0x0.78x1.75
2.2x0.72x2.0
1.45x0.59x1.65
Heater size
m
1.8x0.58x1.35
1.8x0.58x1.35
1.8x0.58x1.35
1.8x0.58x0.35
2.18x0.58x1.35
2.7x0.65x1.65
4.65x0.68x1.5
※We reserve the right to change specifications without prior notice.
