Application:YF series production line is designed for conical or parallel extrusion of PVC plastic window and door's ,steel-plastic composit and decoration profile.
Properties and advantages: This line features stable Plasticization, high output,low sheering force,long life service and other advantages. The production line consists of control system, conical twin screw extruder or parallel twin screw extrud-er,extrusion die,calibration unit,haul off unit,film coveringmachine and stacker.
The extruder is equipped with alternat-ing-current inverter(ABB or Eurotherm drive),imported temperature controller(RKC,Japan). The calibration unit's pump and haul off unit's reducer are famous brand products. After simple ohanging of the die and screw, it also can produce the foam profiles.
Main technical parameter
Model
YF240
YF240
YF240A
Max. width of product(mm)
240
240
150*2
Extruder model
SJP75/28
SJP93/28/31
SJP110/28
Max.extrusion capacity（kg/h）
150-250
250-400
400-500
Extruder power （kw）
37
55
75
Cooling water （m3/h）
7
8
10
Compressed air（m3/min）
0.6
0.6
0.8
※We reserve the right to change specifications without prior notice.
