32 cavity hot runner PET preform mould with standard hardness for cavity and core, Germany steel for cavity and core, high speed injection, fully automatic ejection system, filter design in order to stop waste material come into the mould cavity.
Main mould components (die core, die cavity, screw neck) are made by injection process, and the material of which originates from Sweden high-quality mould steel(HRC 45).In this way, itis no doubt that the mould can be used for 2 million shots without any mainttenance, meanwhile, the wall thickness between max.part and min.part is notmore than 0.10mm; turning center processes make sure that every parts can match well; proper distribution of cooling water way improve productivity effect and molding cycle only takes 15 seconds( need proper water chiller, bottle design and injection machine).
Our mould, designed and developed by our engineers, is of high precision and long life span without traditional problems. In a word, Preform wall thickness is on error of 0.10mm; weight difference is less than 0.3g; 2-5 moulds per minute; 2 million guarantee; utmost 144 cavities in
Specification:
Cavity Number
22g Preform Length:94mm
32g Preform Length:120mm
42g Preform Length:130mm
Dimension(mm)
Weight(kg)
Dimension(mm)
Weight(kg)
Dimension(mm)
Weight(kg)
4(1*4)
500*290*430
550
500*290*445
600
500*290*455
6680
6(2*3)
430*370*400
760
430*370*415
850
430*370*425
900
8(2*4)
490*370*435
810
490*370*450
900
490*370*460
970
12(2*6)
630*370*435
1020
630*370*450
1100
630*370*460
1180
12(2*8)
750*370*480
1240
750*370*495
1350
750*370*505
1450
24(3*8)
830*440*500
1880
830*440*515
1950
830*440*525
2060
32(4*8)
830*580*515
2360
830*580*530
2250
830*580*545
2600
48(4*12)
1065*580*525
2930
1065*580*540
3050
1065*580*555
3150
72(6*12)
1140*830*560
4320
1140*830*575
4450
1140*830*580
※We reserve the right to change specifications without prior notice.
